A = Length × Width300 m²Show Calculation
- Engineering inputs
- Length 20 m; width 15 m
- Formula
- A = L × W
- Substitution
- 20 × 15
- Calculation
- 300 m²
- Final result
- 300 m² room area
INDOOR AIR ENGINEERING
INDOOR AIR ENGINEERING
Continuous Air Hygiene & Oxidation Platform Selection
Select the appropriate BES indoor-air platform and evaluate room coverage, installation architecture, operating profile and engineering suitability.
100–400 m³/hMulti ZoneHydroxylOzoneHybrid
ENGINEERING PLATFORM
Choose the engineering architecture.
Indoor Air Engineering Simulation
Generated when Export PDF is selected
Project / Input Summary
- Platform
- HAS Pro
- Room dimensions
- 20 × 15 × 4 m
- Room area
- 300.0 m²
- Room volume
- 1200.0 m³
- Installation / AC type
- standalone
- Occupancy
- occupied
- Relative humidity
- normal · 55% RH
- Operating schedule
- 24 hours · 24.0 h/day
Live Engineering Result
- Recommended mode
- Level 2 · 200 m³/h
- User-selected mode
- Level 2 · 200 m³/h · mode confirmation required
- Product quantity
- 3 preliminary airflow zones
- Installed nominal coverage
- Engineering data required
- Coverage utilization
- 33.3%
- Engineering status
- PRODUCT DATA REQUIRED
- Installation compatibility
- Compatible commercial-airflow architecture
- Installation recommendation
- Allocate a clear intake and discharge position to each preliminary airflow zone and commission each zone independently.
Calculation Summary
Room area
20 × 15 = 300.0 m²
Room volume
300.0 × 4 = 1200.0 m³
Coverage / airflow utilization
400 ÷ 1200 × 100 = 33.3%
Engineering Recommendation
3 preliminary airflow zones are indicated by the entered 3 zone plan and 400 m³/h airflow. This is an airflow review only; final HAS Pro sizing requires verified coverage and site distribution data.
Engineering Remarks
- Install the product in accordance with the BES Installation Manual.
- Verify proper system operation after installation and commissioning.
- Engineering performance is estimated from the selected operating conditions.
01 / ENGINEERING INPUTS & LIVE RESULT
Validate the selected indoor-air platform
Enter the room and operating conditions to calculate coverage where verified, review operating mode and installation architecture, and identify data still required.
V = Area × Height1,200 m³Show Calculation
- Engineering inputs
- Area 300 m²; height 4 m
- Formula
- V = A × H
- Substitution
- 300 × 4
- Calculation
- 1,200 m³
- Final result
- 1,200 m³ room volume
N = max(Planned zones, Airflow ÷ 400)3 zonesShow Calculation
- Engineering inputs
- 3 planned zones; 400 m³/h requested airflow
- Formula
- N = max(Nzones, ceil(Qrequested ÷ 400))
- Substitution
- max(3, ceil(400 ÷ 400))
- Calculation
- max(3, 1) = 3
- Final result
- 3 preliminary airflow zones
Qinstalled = Quantity × 4001,200 m³/hShow Calculation
- Engineering inputs
- 3 zones; 400 m³/h verified maximum fan level
- Formula
- Qinstalled = N × Qunit
- Substitution
- 3 × 400
- Calculation
- 1,200 m³/h
- Final result
- 1,200 m³/h installed airflow reference
U = Requested airflow ÷ Installed airflow × 10033.3%Show Calculation
- Engineering inputs
- 400 m³/h requested; 1,200 m³/h installed
- Formula
- U = Qrequested ÷ Qinstalled × 100
- Substitution
- 400 ÷ 1,200 × 100
- Calculation
- 33.3%
- Final result
- 33.3% airflow utilization
Preliminary engineering selection only. This workflow does not confirm sterilization, pathogen kill, ozone exposure safety or final commissioning acceptance.
HAS Pro airflow and installation architecture
The BERE blueprint updates product placement, room geometry, airflow direction and engineering annotations from the active platform.
BERE · LIVE ENGINEERING VIEW
HAS PRO airflow and treatment architecture
LIVE MODEL
03 / ENGINEERING PERFORMANCE
Operating performance at a glance
Review the estimated concentration trend against the selected engineering reference and the cumulative exposure trend across the operating window.
CURRENT, STEADY STATE & SELECTED STANDARD
Estimated Ozone Concentration
Show Calculation
- Source
- Selected daily operating time
- Value
- 24 h/day
Show Calculation
- Predicted steady state
- 0.0180 ppm
- Time constant
- 6.0 h
- Current time
- 24 h
- Formula
- C(t) = Csteady × (1 − e^(−t/τ))
- Calculation
- 0.0180 × (1 − e^(−24 / 6.0))
- Result
- 0.0177 ppm
Show Calculation
- Live performance basis
- 100% selected operating duty
- Performance factor
- 1.000
- Unconstrained estimate
- 0.0180 × 1.000 = 0.0180 ppm
- Standard constraint
- 0.050 × 0.92 = 0.0460 ppm
- Formula
- Csteady = min(mode-adjusted estimate, standard × 0.92)
- Result
- 0.0180 ppm
Show Calculation
- Selected reference
- BES Recommendation
- Reference line
- 0.050 ppm
- Use
- Visual engineering comparison; commissioning verification remains required
Show Calculation
- Formula
- Margin = (Standard − Csteady) ÷ Standard × 100
- Calculation
- (0.050 − 0.0180) ÷ 0.050 × 100
- Result
- 64%
Show Calculation
- Comparison
- 0.0180 ppm < 0.050 ppm
- Interpretation
- Predicted steady state remains below the selected reference
- Verification
- Confirm with calibrated on-site measurement during commissioning
ACCUMULATED CONCENTRATION × TIME
Cumulative CT
Show Calculation
- Source
- Selected daily operating time
- Value
- 24 h/day
Show Calculation
- Formula
- CT(t) = ∫C(t)dt
- Analytical method
- CT(t) = 60 × Csteady × [t − τ(1 − e^(−t/τ))]
- Calculation
- 60 × 0.0180 × [24 − 6.0 × (1 − e^(−24 / 6.0))]
- Result
- 20 ppm·min
Show Calculation
- Formula
- CT(24) = 60 × Csteady × [24 − τ(1 − e^(−24/τ))]
- Calculation
- 60 × 0.0180 × [24 − 6.0 × (1 − e^(−24 / 6.0))]
- Result
- 20 ppm·min
Show Calculation
- Method
- Analytical integral of the displayed concentration curve
- Units
- Concentration (ppm) × time (minutes)
- Acceptance
- Engineering trend only; no PASS / FAIL criterion is applied
Performance curves are presentation estimates based on the selected operating duty and do not modify product sizing, recommendation logic or commissioning acceptance.
Decision-ready engineering basis
Five essential checks summarize the active preliminary selection without repeating the detailed input and recommendation panels.
Product SelectedHAS Pro
Coverage1200 m³/h installed airflow
Coverage Utilization33%
Installation CompatibilityCompatible commercial-airflow architecture
Relative Humidity55% RH
Engineering Remarks
- Install the product in accordance with the BES Installation Manual.
- Verify proper system operation after installation and commissioning.
- Engineering performance is estimated from the selected operating conditions.
06 / EXPORT PDF
Export the current engineering configuration
Generate a print-ready BES report containing the live project inputs, diagram, performance graphs, calculation summary, recommendation and engineering remarks.
HAS Pro
A preliminary selection based on the verified platform data and current site inputs.
- Recommended platform
- HAS Pro
- Recommended mode
- Level 2 · 200 m³/h · mode confirmation required
- Preliminary quantity
- 3 preliminary airflow zones
- Installation method
- Allocate a clear intake and discharge position to each preliminary airflow zone and commission each zone independently.
- Operating schedule
- 24.0 h/day
KEY ENGINEERING REASON
3 preliminary airflow zones are indicated by the entered 3 zone plan and 400 m³/h airflow. This is an airflow review only; final HAS Pro sizing requires verified coverage and site distribution data.
Limitations / data still required
- The repository does not provide a verified area or volume coverage rating.
- Confirm treatment mode, zone airflow, occupancy procedure and final unit quantity with BES Engineering.
HAS Pro calculation and airflow basis
Detailed engineering interpretation follows the platform’s verified architecture rather than forcing every product into one generic formula.
Use only the verified 100, 200 and 400 m³/h fan levels.
Partitions and return paths define the preliminary zone count.
No area or volume rating is invented for final sizing.
HAS PRO AIRFLOW ARCHITECTURE
CENTRAL / ZONE RETURNS→HAS PRO→100 / 200 / 400 m³/h→MULTIPLE ENGINEERED ZONES
Review airflow and zoning without assigning an unverified room-coverage rating.
Survey partitions, doors, intake paths and discharge paths.
Allocate one clear position to each preliminary airflow zone.
Maintain the documented inlet and side clearances.
Confirm mode, airflow and final quantity with BES Engineering.
This is an engineering screening workflow, not a clinical claim. It does not confirm sterilization, pathogen kill, log reduction or safe ozone exposure.
