A = Length × Width48 m²Show Calculation
- Engineering inputs
- Length 8 m; width 6 m
- Formula
- A = L × W
- Substitution
- 8 × 6
- Calculation
- 48 m²
- Final result
- 48 m² room area
INDOOR AIR ENGINEERING
INDOOR AIR ENGINEERING
Continuous Air Hygiene & Oxidation Platform Selection
Select the appropriate BES indoor-air platform and evaluate room coverage, installation architecture, operating profile and engineering suitability.
Continuous24 HoursHVAC IntegratedLow OzoneROS Generation
ENGINEERING PLATFORM
Choose the engineering architecture.
Indoor Air Engineering Simulation
Generated when Export PDF is selected
Project / Input Summary
- Platform
- HAS
- Room dimensions
- 8 × 6 × 2.8 m
- Room area
- 48.0 m²
- Room volume
- 134.4 m³
- Installation / AC type
- fan coil
- Occupancy
- occupied
- Relative humidity
- normal · 55% RH
- Operating schedule
- 24 hours · 24.0 h/day
Live Engineering Result
- Recommended mode
- Mode II · 50 m²
- User-selected mode
- Auto · Mode II
- Product quantity
- 1 preliminary unit
- Installed nominal coverage
- 50.0 m²
- Coverage utilization
- 96.0%
- Engineering status
- ENGINEERING REVIEW REQUIRED
- Installation compatibility
- Compatible architecture
- Installation recommendation
- Integrate at the fan coil treatment point upstream of the fan coil or AHU supply path.
Calculation Summary
Room area
8 × 6 = 48.0 m²
Room volume
48.0 × 2.8 = 134.4 m³
Coverage / airflow utilization
48.0 ÷ 50.0 × 100 = 96.0%
Engineering Recommendation
Use HAS Mode II for the 48 m² room, with the treatment point integrated into the verified return-air path. The selected schedule supports the continuous operating concept.
Engineering Remarks
- Install the product in accordance with the BES Installation Manual.
- Verify proper system operation after installation and commissioning.
- Engineering performance is estimated from the selected operating conditions.
01 / ENGINEERING INPUTS & LIVE RESULT
Validate the selected indoor-air platform
Enter the room and operating conditions to calculate coverage where verified, review operating mode and installation architecture, and identify data still required.
V = Area × Height134.4 m³Show Calculation
- Engineering inputs
- Area 48 m²; height 2.8 m
- Formula
- V = A × H
- Substitution
- 48 × 2.8
- Calculation
- 134.4 m³
- Final result
- 134.4 m³ room volume
U = Area ÷ Installed coverage × 10096%Show Calculation
- Engineering inputs
- Area 48 m²; installed coverage 50 m²
- Formula
- U = A ÷ Cinstalled × 100
- Substitution
- 48 ÷ 50 × 100
- Calculation
- 96%
- Final result
- 96% coverage utilization
Preliminary engineering selection only. This workflow does not confirm sterilization, pathogen kill, ozone exposure safety or final commissioning acceptance.
HAS airflow and installation architecture
The BERE blueprint updates product placement, room geometry, airflow direction and engineering annotations from the active platform.
BERE · LIVE ENGINEERING VIEW
HAS airflow and treatment architecture
LIVE MODEL
03 / ENGINEERING PERFORMANCE
Operating performance at a glance
Review the estimated concentration trend against the selected engineering reference and the cumulative exposure trend across the operating window.
CURRENT, STEADY STATE & SELECTED STANDARD
Estimated Ozone Concentration
Show Calculation
- Source
- Selected daily operating time
- Value
- 24 h/day
Show Calculation
- Predicted steady state
- 0.0180 ppm
- Time constant
- 6.0 h
- Current time
- 24 h
- Formula
- C(t) = Csteady × (1 − e^(−t/τ))
- Calculation
- 0.0180 × (1 − e^(−24 / 6.0))
- Result
- 0.0177 ppm
Show Calculation
- Live performance basis
- 12 mg/h selected-mode output ÷ 12 mg/h Mode II reference
- Performance factor
- 1.000
- Unconstrained estimate
- 0.0180 × 1.000 = 0.0180 ppm
- Standard constraint
- 0.050 × 0.92 = 0.0460 ppm
- Formula
- Csteady = min(mode-adjusted estimate, standard × 0.92)
- Result
- 0.0180 ppm
Show Calculation
- Selected reference
- BES Recommendation
- Reference line
- 0.050 ppm
- Use
- Visual engineering comparison; commissioning verification remains required
Show Calculation
- Formula
- Margin = (Standard − Csteady) ÷ Standard × 100
- Calculation
- (0.050 − 0.0180) ÷ 0.050 × 100
- Result
- 64%
Show Calculation
- Comparison
- 0.0180 ppm < 0.050 ppm
- Interpretation
- Predicted steady state remains below the selected reference
- Verification
- Confirm with calibrated on-site measurement during commissioning
ACCUMULATED CONCENTRATION × TIME
Cumulative CT
Show Calculation
- Source
- Selected daily operating time
- Value
- 24 h/day
Show Calculation
- Formula
- CT(t) = ∫C(t)dt
- Analytical method
- CT(t) = 60 × Csteady × [t − τ(1 − e^(−t/τ))]
- Calculation
- 60 × 0.0180 × [24 − 6.0 × (1 − e^(−24 / 6.0))]
- Result
- 20 ppm·min
Show Calculation
- Formula
- CT(24) = 60 × Csteady × [24 − τ(1 − e^(−24/τ))]
- Calculation
- 60 × 0.0180 × [24 − 6.0 × (1 − e^(−24 / 6.0))]
- Result
- 20 ppm·min
Show Calculation
- Method
- Analytical integral of the displayed concentration curve
- Units
- Concentration (ppm) × time (minutes)
- Acceptance
- Engineering trend only; no PASS / FAIL criterion is applied
Performance curves are presentation estimates based on the selected operating duty and do not modify product sizing, recommendation logic or commissioning acceptance.
Decision-ready engineering basis
Five essential checks summarize the active preliminary selection without repeating the detailed input and recommendation panels.
Product SelectedHAS
Coverage50 m²
Coverage Utilization96%
Installation CompatibilityCompatible architecture
Relative Humidity55% RH
Engineering Remarks
- Install the product in accordance with the BES Installation Manual.
- Verify proper system operation after installation and commissioning.
- Engineering performance is estimated from the selected operating conditions.
06 / EXPORT PDF
Export the current engineering configuration
Generate a print-ready BES report containing the live project inputs, diagram, performance graphs, calculation summary, recommendation and engineering remarks.
HAS
A preliminary selection based on the verified platform data and current site inputs.
- Recommended platform
- HAS
- Recommended mode
- Mode II · 50 m² nominal coverage
- Preliminary quantity
- 1 preliminary unit
- Installation method
- Integrate at the fan coil treatment point upstream of the fan coil or AHU supply path.
- Operating schedule
- 24.0 h/day
KEY ENGINEERING REASON
Use HAS Mode II for the 48 m² room, with the treatment point integrated into the verified return-air path. The selected schedule supports the continuous operating concept.
Limitations / data still required
- Confirm measured airflow and return-path distribution.
- Verify current manual, water quality, occupied-zone conditions and local ozone requirements.
HAS calculation and airflow basis
Detailed engineering interpretation follows the platform’s verified architecture rather than forcing every product into one generic formula.
Match the room area to the verified Mode I–IV table.
Utilization is informational and never proves final performance.
Commission the complete recirculation path.
HAS AIRFLOW ARCHITECTURE
RETURN AIR→HAS INJECTION / TREATMENT→FAN COIL / AHU→SUPPLY AIR → ROOM → RETURN
Integrate the treatment point with a verified HVAC or fan-coil return path.
Confirm return and supply airflow direction.
Install the HAS treatment point at the fan-coil or AHU return path.
Use RO, DI or distilled water as specified.
Verify distribution, humidity and occupied-zone conditions during commissioning.
This is an engineering screening workflow, not a clinical claim. It does not confirm sterilization, pathogen kill, log reduction or safe ozone exposure.
