EXTERNAL INSTALLATION01
Small Examination Room
Installed immediately beside the wall-mounted air conditioner so the room airflow carries treated air through the compact clinical zone.
BES Indoor Air Product Family
Compact Local Air Hygiene
HAS Mini
Compact Air Hygiene System
Localized humidified ozone and ROS support for compact occupied environments.
- Compact personal and mobile format
- USB-C / DC 5V operation
- Passive distribution with ambient room airflow
- Four official operating modes
CE Mark: Conformité Européenne- Technology
- Electrolytic Aqueous Ozone (EOG)
- Model
- EOS7170-S
- Output
- 10–15 mg/h (±10%)
KEY HIGHLIGHTS
✓ Compact design
✓ Local area support
✓ Easy deployment
✓ Suitable for small rooms
APPLICATIONS
✓ Office
✓ Clinic
✓ Pet grooming
✓ Small room odor control
PRODUCT SPECS
Technology
Electrolytic Aqueous Ozone (EOG)
Model
EOS7170-S
Ozone Output
10–15 mg/h (±10%)
Ozone Purity
≈20 wt% / NOx free
Flow Pressure
Max 0.2 Bar
Input
AC 100–240V, 50/60Hz / DC 5V 1A
Rated Power
<5 W
Water Requirement
DI / distilled water, conductivity <5 μS/cm
Water Storage
125 ml (90 ml effective)
Water Consumption
≈0.15 ml/h
Working Temperature
1–40°C
Working Humidity
0–90% non-condensing
Material
ABS casing / PTFE tubing
Dimensions
42.5 × 118.5 × 107 mm
Weight
231 g net / 370 g filled with bracket
Protection Class
IPX2
EOG Lifetime
1000 hrs / 2000 hrs option
HAS MINI · USE CASES
Compact installation, exactly where treatment is needed
Each example uses the same real HAS Mini product photograph. Placement remains external, accessible, and close to the intended airflow or treatment point.
EXTERNAL INSTALLATIONEXTERNAL INSTALLATION02
Ambulance / Medical Van
A compact wall installation keeps the unit visible and accessible inside the patient cabin without obstructing the treatment area.
EXTERNAL INSTALLATION03
Sushi / Food Display Refrigerator
Mounted externally, directly beside the refrigerated display, with a short delivery path to the controlled cabinet zone.
EXTERNAL INSTALLATION04
Ice Machine
A compact external installation beside the machine keeps the HAS Mini outside the ice bin and clear of service access.
Conceptual placement shown for planning. Final mounting, tubing, duty mode, ventilation, and safety requirements must follow the current HAS Mini manual and site engineering review.
INSTALLATION GUIDE
HAS Mini placement and commissioning
Portable installation guidance from the existing Indoor Air product profile and controlled product documentation.
1
Local placement
Mount on a stable surface close to the intended delivery point and protect the unit from prolonged direct sunlight.
2
Free-flow delivery
Complete all tubing before power-up and keep the ozone delivery path unobstructed.
3
Mode commissioning
Select continuous or intermittent duty to match the approved small-zone operating plan.
PRODUCT ENGINEERING SIMULATION
HAS Mini operation mode selector
Evaluate this product using its original product-specific operating logic. For full cross-platform site design, continue to the Indoor Air Engineering Application.
24-HOUR OPERATING PROFILERepeated EOG duty during the selected treatment period
Official EOG ON fraction Standby / outside treatment period
VIDEO LIBRARY
Product videos
Verified Certification Profile
Open BES Certification Center Certifications
Certification claims are read from the shared BES certification registry. Available controlled documents are linked from the product resource center.
RELATED SOLUTIONS
Connect this product to applications
FAQ
HAS Mini product questions
Where is system sizing completed?
Room conditions, coverage, quantity and operating strategy are evaluated in the Indoor Air Engineering application. This page documents the product itself.
Which water and installation requirements apply?
Use the water quality, clearance, power and mounting requirements stated in the current product manual. Site conditions should be reviewed before installation.
What operating patterns are available?
The English manual identifies continuous operation plus 10/10, 5/15 and 5/25 minute intermittent patterns.
